Yangdong stock

I. INTRODUCTION of Yangdong stock series

YiTuo (Jiangyan) Power Machinery Co., Ltd. is a subsidiary of China YiTuo Group Co., Ltd. established on the basis of Yangdong Co., Ltd. The company successfully developed the first 480 diesel engine for vehicles in China in 1984. After more than 20 years of development, it has now become one of the production bases of multi-cylinder diesel with the most varieties, the most complete specifications and the largest scale in China, with the ability to produce 300000 multi-cylinder diesel engines annually. There are 18 kinds of basic multi-cylinder diesel engines with power coverage of 10-105kW. The products are mainly applicable to the matching of passenger cars, commercial vehicles, low-speed trucks, tractors, combine harvesters, construction machinery, marine units, generator sets, water pump units, passenger car air conditioning units, etc. Driven diesel engine has become the preferred power for many customers due to its remarkable advantages such as strong power, reliable performance, economy and durability, low vibration and low noise.

Features of Yangyang stock generator set

Stable and reliable unit performance

Low fuel consumption, low emission and low noise

The diesel generator set adopts rotary diesel, oil filter and dry air filter. The generator set is wear-resistant, durable, compact in structure and convenient to operate.

In addition to water-cooled units, the products also have air-cooled units and oil-cooled units suitable for water source difficulties and start-up difficulties. The product specifications are complete and there are many varieties.

Compact structure, small volume and light weight

Stable and reliable performance with a failure-free interval of up to 6500 hours

General maintenance is easy, and the operation and use technology is gradually familiar to Chinese customers.

Pay attention to environmental protection requirements, low exhaust emission pollution, meet the most stringent emission regulations in Europe and North America, excellent durability, long service life, overhaul time up to 20000 hours

Units in each power section of Yangdong stock series

Parameter list of each power segment of Yangdong series diesel generator set open frame model

Unit Model	Rated Power(KW)	Motor capacity(KVA)	Engine model	Fuel consumption power(≤ g/kw. h)	Engine				Rated current(A)	Unit weight(KG)	Dimensions(L * W * Hm m)
					1HPower consumption	Cylinder number	Cylinder diameter* Itinerary	Displacement
YX9GF	9	11.25	YD380D	260	10	L3	80*90	1.357	16.2	560	1300*700* 1000
YX10G F	10	12.5	YD385D	255	11	L3	85*90	1.532	18	600	1300*700* 1000
YX12G F	12	15	YD480D	250.5	14	L4	80*90	1.809	21.6	680	1500*700* 1000
YX15G F	15	18.75	YND485 D	247	17	L4	85*95	2.156	27	750	1600*750* 1200
YX18G F	18	22.5	YSD490 D	247.5	21	L4	90*100	2.54	32.4	750	1600*750* 1200
YX20G	20	25	Y490D	247.5	24	L4	90*1	2.67	36	580	1600*750

Unit Model	Rated Power(KW)	Motor capacity(KVA)	Engine model	Fuel consumption power(≤ g/kw. h)	Engine				Rated current(A)	Unit weight(KG)	Dimensions(L * W * Hm m)
					1HPower consumption	Cylinder number	Cylinder diameter* Itinerary	Displacement
F							05				* 1500
YX22G F	22	27.5	YND485 ZLD	247	25	L4	85*95	2.67	39.6	600	1600*750* 1500
YX22G F	22	27.5	Y495D	242	27	L4	95*105	2.977	39.6	580	1600*750* 1500
YX24G F	24	30	Y4100D	237	30	L4	100 *118	3.707	43.2	580	1600*750* 1500
YX24G F	24	30	YSD490 ZLD	242	32	L4	90*105	2.977	43.2	600	1600*750* 1500
YX30G F	30	37.5	Y4102D	235	33	L4	102 *118	3.875	54	800	1650*750* 1200
YX34G F	34	42.5	Y4105D	232	38	L4	105 *118	4.1	61.2	870	1750*750* 1200
YX38G F	38	47.5	Y4108D	230	42	L4	108 *118	4.324	68.4	870	1750*750* 1200
YX40G F	40	50	Y4102Z LD	225	48	L4	102 *118	3.875	72	900	1800*750* 1200
YX50G F	50	62.5	Y4105Z LD	220	55	L4	105 *118	4.1	90	900	1800*750* 1200
YX50G F	50	62.5	YD4EZL D	218	63	L4	105 *118	4.1	90	900	1800*750* 1200

1. The frequency of the motor group of Yangdong stock is 50HZ, 1500rpm, 400V, the power factor is 0.8 (LAG), three-phase and four-wire. If you need other models with special requirements, please contact us to provide additional parameters.
2. The contents of this atlas are for reference only and are not used as delivery materials. The continuous improvement of technology is without prior notice. The product model, specification, configuration and pictures are subject to the physical objects at the time of delivery. Yuxing power reserves the final right of interpretation.

Parameter list of each power segment of Yangdong diesel generator set mute model

Unit Model	Rated Power(KW)	Motor capacity(KVA)	Engine model	Fuel consumption power(≤ g/kw. h)	Engine				Rated current(A)	Unit weight(KG)	Dimensions(L * W * Hmm?)
					1HPower consumption	Cylinder number	Cylinder diameter* Itinerary	Displacement
YX9GF	9	11.25	YD380 D	260	10	L3	80*90	1.357	16.2	730	1900*950 *1250
YX10G F	10	12.5	YD385 D	255	11	L3	85*90	1.532	18	730	1900*950 *1250
YX12G F	12	15	YD480 D	250.5	14	L4	80*90	1.809	21.6	750	2000*950 *1250
YX15G F	15	18.75	YND48 5D	247	17	L4	85*95	2.156	27	800	2000*950 *1250
YX18G F	18	22.5	YSD49 0D	247.5	21	L4	90*100	2.54	32.4	870	2100*950 *1250
YX20G F	20	25	Y490D	247.5	24	L4	90*105	2.67	36	890	2100*950 *1250
YX22G F	22	27.5	YND48 5ZLD	247	25	L4	85*95	2.67	39.6	890	2100*950 *1250
YX22G F	22	27.5	Y495D	242	27	L4	95*105	2.977	39.6	900	2100*950 *1250
YX24G F	24	30	Y4100 D	237	30	L4	100 *118	3.707	43.2	1050	2280*1000* 1250
YX24G F	24	30	YSD49 0ZLD	242	32	L4	90*105	2.977	43.2	1050	2280*1000* 1250
YX30G F	30	37.5	Y4102 D	235	33	L4	102 *118	3.875	54	1050	2280*1000* 1250
YX34G F	34	42.5	Y4105 D	232	38	L4	105 *118	4.1	61.2	1220	2400*1000* 1250
YX38G F	38	47.5	Y4108 D	230	42	L4	108 *118	4.324	68.4	1220	2400*1000* 1250
YX40G F	40	50	Y4102 ZLD	225	48	L4	102 *118	3.875	72	1350	2400*1000* 1250

Unit Model	Rated Power(KW)	Motor capacity(KVA)	Engine model	Fuel consumption power(≤ g/kw. h)	Engine				Rated current(A)	Unit weight(KG)	Dimensions(L * W * Hmm?)
					1HPower consumption	Cylinder number	Cylinder diameter* Itinerary	Displacement
YX50G F	50	62.5	Y4105 ZLD	220	55	L4	105 *118	4.1	90	1420	2500*1000* 1250
YX50G F	50	62.5	YD4EZ LD	218	63	L4	105 *118	4.1	90	1420	2500*1000* 1250

1. The frequency of the motor group of Yangdong stock is 50HZ, 1500rpm, 400V, the power factor is 0.8 (LAG), three-phase and four-wire. If you need other models with special requirements, please contact us to provide additional parameters.
2. The contents of this atlas are for reference only and are not used as delivery materials. The continuous improvement of technology is without prior notice. The product model, specification, configuration and pictures are subject to the physical objects at the time of delivery. Yuxing power reserves the final right of interpretation.
