I. INTRODUCTION of silent generator set Series Introduction of silent generator set
The difference between the silent generator set and the general generator set is mainly that the silent generator set is added with a very effective sound elimination device, which is mainly used in families and places with high requirements for noise control. The quark mute generator set has the characteristics of small volume, light weight, compact structure, beautiful sound insulation cover, simple disassembly and assembly, convenient operation, excellent performance, reliable operation and so on. It is mainly used in hospitals, hotels, communication industry and other fields.
Characteristics of Kubota generator set
Kubota small lightweight high horsepower engine enjoys a good reputation in the global market. In order to meet various demands of industrial engines, we not only provide a full range of products with various horsepower below 85KW, but also provide various corresponding fuels such as diesel, gasoline, liquefied petroleum gas, natural gas, etc. The biggest advantage of Kubota engine is its technical capability and advanced application engineering force corresponding to environmental requirements. Kubota, founded in 1993, took the lead in becoming a global company that has obtained the exhaust emission regulation certification (CARB) of California Air Resources Commission. Since then, Kubota, as the pioneer of environmental protection technology, has always been in a leading position in compliance with the strict exhaust emission restrictions of various countries in the world. With the accumulation and accumulation of nearly one hundred years of history and rich experience, Kubota engine makes the most perfect match between the engine and the Machine, and provides our customers with the most suitable engine works of the machine carried by Kubota. In addition, in order to provide jiubaotian’s engine products to machinery manufacturers carrying out production activities around the world in the first place, we are choosing the most suitable place as our production base.
Kubota series units in each power section
Parameter list of each power segment of Kubota series
Open frame model
| Unit Model | Rated Power(K W) | Motor capacity(KV A) | Engine model | Fuel consumption power(≤ g/kw?. h) | Engine | Rated current(A) | Unit weight(K G) | Dimensions(L * W * H mm) | |||
| 1H power | Cylinder number | Cylinder diameter* Itinerary | Displacement | ||||||||
| YX8GF | 8 | 10 | D1105-E2B G-CHN-1 | 247 | 9.5 | L3 | 78*78.4 | 1.123 | 14.4 | 550 | 1460*730*1170 |
| YX10G F | 10 | 12.5 | V1505-E2B G-CHN-1 | 247 | 12.5 | L4 | 78*78.4 | 1.498 | 18 | 560 | 1500*730*1170 |
| YX12G F | 12 | 15 | D1703-E2B G-CHN-1 | 233 | 15 | L3 | 87*92.4 | 1.647 | 21.6 | 620 | 1460*730*1170 |
| YX16G F | 16 | 20 | V2203-E2B G-CHN-1 | 233 | 20.1 | L4 | 87*92.4 | 2.197 | 28.8 | 650 | 1650*730*1170 |
| YX18G F | 18 | 22.5 | V2003-T-E 2BG-CHN-1 | 233 | 22.5 | L4 | 83*92.4 | 1.999 | 32.4 | 700 | 1650*730*1170 |
| YX24G F | 24 | 30 | V3300-E2B G2-CHN-1 | 243 | 28.9 | L4 | 98*110 | 3.318 | 43.2 | 734 | 1910*730*1170 |
| YX30G F | 30 | 37.5 | V3300-T-E 2BG2-CHN-1 | 236 | 35.3 | L4 | 98*110 | 3.318 | 54 | 800 | 1910*730*1170 |
- Kubota generator set frequency 50HZ, 1500rpm, 400V, power factor 0.8 (LAG), three-phase four-wire, if you need other special requirements, please contact us to provide additional parameters.
- The contents of this atlas are for reference only and are not used as delivery materials. The continuous improvement of technology is without prior notice. The product model, specification, configuration and pictures are subject to the physical objects at the time of delivery. Yuxing power reserves the final right of interpretation.
Parameter list of each power segment of Kubota diesel generator set mute model
Mute model
| Unit Model | Rated Power(K W) | Motor capacity(KV A) | Engine model | Fuel consumption power(≤ g/kw?. h) | Engine | Rated current(A) | Unit weight(KG) | Dimensions(L * W * H mm) | |||
| 1H power | Cylinder number | Cylinder diameter* Itinerary | Displacement | ||||||||
| YX8GF | 8 | 10 | D1105-E2B G-CHN-1 | 247 | 9.5 | L3 | 78*78.4 | 1.123 | 14.4 | 606 | 1920*900*1210 |
| YX10G F | 10 | 12.5 | V1505-E2B G-CHN-1 | 247 | 12.5 | L4 | 78*78.4 | 1.498 | 18 | 634 | 1920*900*1210 |
| YX12G F | 12 | 15 | D1703-E2B G-CHN-1 | 233 | 15 | L3 | 87*92.4 | 1.647 | 21.6 | 683 | 1920*900*1210 |
| YX16G F | 16 | 20 | V2203-E2B G-CHN-1 | 233 | 20.1 | L4 | 87*92.4 | 2.197 | 28.8 | 744 | 1920*900*1210 |
| YX18G F | 18 | 22.5 | V2003-T-E 2BG-CHN-1 | 233 | 22.5 | L4 | 83*92.4 | 1.999 | 32.4 | 808 | 2120*900*1210 |
| YX24G F | 24 | 30 | V3300-E2B G2-CHN-1 | 243 | 28.9 | L4 | 98*110 | 3.318 | 43.2 | 1084 | 2220*970*1420 |
| YX30G F | 30 | 37.5 | V3300-T-E 2BG2-CHN-1 | 236 | 35.3 | L4 | 98*110 | 3.318 | 54 | 1117 | 2220*970*1420 |
- Kubota generator set frequency 50HZ, 1500rpm, 400V, power factor 0.8 (LAG), three-phase four-wire, if you need other special requirements, please contact us to provide additional parameters.
The contents of this atlas are for reference only and are not used as delivery materials. The continuous improvement of technology is without prior notice. The product model, specification, configuration and pictures are subject to the physical objects at the time of delivery. Yuxing power reserves the final right of interpretation.
